    Boiler EN 10216-2 P195GH High Pressure Steel Tube (Custom Made)

    Ask Lasest Price
    Brand Name : FRANK STEEL
    Model Number : EN 10216-2 P195GH
    Certification : DNV / LR / BV
    Price : USD negotiation per Ton
    Payment Terms : T/T
    Supply Ability : 1000 Ton per 30 days
    Delivery Time : about 30 work days
    • Product Details
    • Company Profile

    Boiler EN 10216-2 P195GH High Pressure Steel Tube (Custom Made)

    EN 10216-2 P195GH seamless steel tube for high temperature and high pressure purpose


    Need quotation? Please let us know OD, wall thickness and length.


    1. Product Description


    En10216-2 P195GH is a seamless steel pipe for high temperature and high pressure. Its products are widely used in boilers, heating pipes, superheaters, reheaters, pressure vessels and instruments.


    The main materials are P195GH, P235GH and P265GH. They have different inspection requirements, chemical composition and mechanical properties. Customers can choose their own products according to their own needs. Please refer to the table below for specific chemical composition and physical properties.


    According to the internal regulations of CEN / CENELEC, the following countries are using this standard: Austria Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Luxembourg, Malta, the Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, the United Kingdom, after years of efforts, our customers have been sold to the above countries, product quality and service, their trust and praise.


    The EN10216-2 P195GH standard seamless steel pipe for export can be painted and marked on the surface, chamfered, threaded at both ends, and blunt. The two ends of the steel pipe can be provided with pipe caps and protective covers. Various export packaging methods can ensure the safe transportation of products.


    2. Chemical composition

    StandardsSteel pipes No.Chemical composition(%)
    CSiMnPSCrMoCuNiVAlWNbN
    EN1021 6-215NiCuMoNb5-6-4 (WB36)≤0.170.25~0.500.80~1.20≤0.025≤0.020≤0.300.25~0.500.50~0.801.00~1.30 ≤0.05 0.015~0.045
    P195GH≤0.13≤0.35≤0.70≤0.025≤0.020≤0.30≤0.08
    P235GH≤0.16≤0.35≤1.20≤0.025≤0.020≤0.30≤0.08
    P265GH≤0.20≤0.40≤1.40≤0.025≤0.020≤0.30≤0.08
    20MnNb6≤0.220.15~0.351.00~1.50≤0.025≤0.020//
    16Mo30.12~0.20≤0.350.40~0.90≤0.025≤0.020≤0.30≤0.08

    3. Physical Properties

    StandardsSteel pipes No.Tensile strength(MPa)Bend strength(MPa)Elongation(%)Impact energy(J)Hardness
    EN10216-215NiCuMoNb5-6-4 (WB36)610~780≥440≥19
    P195GH320~440≥19527
    P235GH360~500≥23825
    P265GH410~570≥26523
    20MnNb6500~650≥35522
    16Mo3450~600≥28022

    4. Details Picture

    Quality Boiler EN 10216-2 P195GH High Pressure Steel Tube (Custom Made) for sale
